Overview

Home SRT Overview

In 2016, SR will operate SRT over the Gyeongbu high speed line and the Honam high speed line.
Each train consists of 10 cars including the power and passenger cars, and the company plans to run a fleet of 32 trains.

Specifications


Length	Width	Weight	Seats	Manufacture	Hyundai Rotem Company
201m	2.97m	406t	410	Cars per train	10 Cars including 2 power cars and 8 passenger car
Gross Weight : 406ton (without passengers) Seats : Transport capacity increased by 13% compared from the existing train (363 seats).				Speed	Maximum operating speed 300km/h (Maximum design speed 330km/h)


Length	Width	Weight	Seats
201m	2.97m	406t	410
Gross Weight : 406ton (without passengers) Seats : Transport capacity increased by 13% compared from the existing train (363 seats).


Manufacture	Hyundai Rotem Company
Cars per train	10 Cars including 2 power cars and 8 passenger car
Speed	Maximum operating speed 300km/h (Maximum design speed 330km/h)

New Features

SRT has significantly improved safety features, such as improved window structures in passenger cars , upgraded handles, reformed footholds of doors, and fire alarms that detect heat and smoke simultaneously.

Passenger Car Windows

By adopting a single window system, the viewing angle from the inside is maintained, whereas the areas exposed to the outside are minimized, reducing damage to the window.
Front Windows

2D-curved glass improves distortion of images and improves the view.
Wipers

Spare wipers are installed which can be operated by air pressure, even when the electricity is cut off.
Side Buffers

Head joints of side buffers connecting power cars with passenger cars are manufactured as an integral form enhancing strength and safety.
Hatch Controller

Diagnostic control equipment has been upgraded, in case of any emergency.
Pantograph Controller

To prevent dust inflow, the pantograph controller is improved to a box type structure.
